Unit Calculated Volume
0.002862
Unit Calculated Weight
0.643
Units per Shipping Box
20
International Protection (IP) code
IP67
Connectivity technology
Wired
Minimum illumination
0.0008
Optical sensor size
1/2.9
Maximum resolution
2688 x 1520
Video compression formats
H.264/H.264+/H.264B/H.264H/H.265/H.265+/M-JPEG
Compatible memory cards
MicroSD (TransFlash)
Maximum memory card size
256
Ethernet LAN (RJ-45) ports
1
Operating temperature (T-T)
-40 - 60
Adjustment shutter speed
Auto/Manual
Camera shutter speed
1/3 - 1/100000
Summary
Dahua Technology WizSense IPC-HFW2449S-S-IL. Type: IP security camera, Placement supported: Indoor & outdoor, Connectivity technology: Wired. Mounting type: Ceiling/wall, Product colour: White, Form factor: Bullet. Minimum illumination: 0.0008 lx, Angle of rotation: 360°, Tilt angle range: 0 - 90°. Sensor type: CMOS, Optical sensor size: 25.4 / 2.9 mm (1 / 2.9"). Closest focusing distance: 0.9 m
Placement supported
Indoor & outdoor
Mounting type
Ceiling/wall
Number of illumination LEDs
1
Back Light Compensation (BLC)
Yes
Highlight Compensation (HLC)
Yes
Noise reduction technology
3D noise reduction
Supported graphics resolutions
1280 x 720 (HD 720)/1280 x 960/1920 x 1080 (HD 1080)/2304 x 1296/2560 x 1440/2688 x 1520/342 x 240/352 x 288/640 x 480 (VGA)/704 x 480/704 x 576
Ethernet interface type
Fast Ethernet
Supported network protocols
IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; NTP; Multicast; ICMP; IGMP
Video motion detection
Yes
Power consumption (max)
4.4
Certification
CE-LVD: EN 62368-1
CE-EMC: 2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B
Wide Dynamic Range (WDR)
Yes
Maximum aperture number
1.6
Card reader integrated
Yes
Intelligent Video Surveillance (IVS) system features
Intrusion/Tripwire
Management software
DSS; DMSS
Region of Interest (ROI) encoding
Yes
Bit rate control
Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
Signal-to-Noise Ratio (SNR)
56
Power consumption (typical)
2.1
Operating relative humidity (H-H)
0 - 95
Storage temperature (T-T)
-40 - 60
Power consumption (Power over Ethernet (PoE))
2.5
White balance
Auto/Manual/Natural/Outdoor/Street lamp
Gain control type
Auto/Manual
Audio formats supported
G.711 µ-law/G.711 A-law/G.726/PCM
Mobile operating systems supported
Android/iOS
Closest focusing distance
0.9
Long Description
Dahua Technology WizSense IPC-HFW2449S-S-IL. Type: IP security camera, Placement supported: Indoor & outdoor, Connectivity technology: Wired. Mounting type: Ceiling/wall, Product colour: White, Form factor: Bullet. Minimum illumination: 0.0008 lx, Angle of rotation: 360°, Tilt angle range: 0 - 90°. Sensor type: CMOS, Optical sensor size: 25.4 / 2.9 mm (1 / 2.9"). Closest focusing distance: 0.9 m
Bullet Points
- 4-MP 1/2.9" CMOS image sensor, low luminance, and high definition image
- Outputs max. 4 MP (2688 × 1520)@20 fps, and supports 2560 × 1440 @25/30 fps
- H.265 codec, high compression rate, ultra-low bit rate
- Built-in warm light/IR LED, the max. illumination distance is 30 m and the max. warm light distance is 30 m
- ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments
- Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes
- Intelligent monitoring: Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human)
- Supports max. 256 G Micro SD card; built in MIC
- 12 VDC/PoE power supply, easy for installation
- IP67 protection
- SMD Plus
Name
NET CAMERA 4MP IR BULLET/IPC-HFW2449S-S-IL-0280B DAHUA
